Telangana Cadastral Map, Tippon & FMB Sketch: How to Get Copies

Your sale deed is registered, your Pattadar Passbook is in hand, and the buyer’s bank has approved the loan. Then the sub-registrar’s office asks for a Tippon, and the deal stalls because your village’s sketch shows a boundary that doesn’t match what’s on the ground,

or worse, you can’t produce a certified copy at all. This is a common scene in Telangana, where ownership papers and measurement records are two separate things, and most landowners only discover the gap when a transaction is already underway.

This guide covers what a cadastral map Telangana records actually contain, how Tippon and FMB sketches differ (and whether they differ at all), and the practical route to obtaining a certified copy online for reference, offline for legal use. It’s written for anyone who needs the document in hand, not just an explanation of what it is.

What a Cadastral Map Actually Shows

A cadastral map is the official village-level map: every survey number, every plot boundary, every adjoining parcel, all drawn to a fixed scale. In Telangana, these are also called village maps, and they function as the master reference for all land in that village.

Zoom into a single survey number on that map, and you reach the field-level detail. That detail is the Tippon also spelled Tippan and the FMB sketch. These aren’t separate documents competing for your attention. They’re the measurement sheets that feed into the larger village map.

The Survey and Land Records Department maintains all of this under the Survey and Boundaries Act, 1923. Its job is to keep survey marks, Tippons, village plans, and settlement registers current as land is sold, subdivided, or acquired.

Tippon, Tippan, FMB: What’s the Difference?

In practice, nothing. Telangana landowners, surveyors, and sub-registrar staff use Tippon, Tippan, and FMB sketch interchangeably for the same thing: a one-page field sketch showing the exact dimensions of a single survey number or subdivision.

The terminology has history behind it. Tippon is the older word, dating to the original cadastral surveys. Many Tippons in Telangana were drafted in Marathi or Urdu between the 1960s and 1970s and survive as fragile paper sheets in district survey offices.

FMB stands for Field Measurement Book the bound volume that compiles these individual sketches. Request an FMB copy for your survey number, and you’re asking for the Tippon page corresponding to your plot.

A typical Tippon sheet contains:

• F-line the actual field boundary, marking the outer edges of the survey number.
• G-line the base line used to construct the sketch, often an imaginary line that splits the plot into measurable triangles.
• Ladder diagram offset measurements that fix each boundary point relative to the base line.
• Subdivision lines where the original survey number has been split, these show the sub-divisions (112/1, 112/2, and so on).
• Adjoining survey numbers the bordering plots, which help confirm the sketch’s accuracy.

For any legal or registration purpose, you need a certified Tippon carrying the surveyor’s seal and signature. A photocopy or a phone screenshot won’t be accepted.

You may also like to read these posts :👇

How to Check Land Owner Name & Property Details in Telangana

Land Record Search by Name Online: State-wise Guide

తెలంగాణ భూమి రికార్డులు: సర్వే నంబర్‌తో భూమి వివరాలు తెలుసుకోవడం ఎలా

Telangana Revenue Department: Services, Officer Hierarchy & Contacts

Why the Tippon Matters More Than You Think

A sale deed or Pattadar Passbook establishes that you own a survey number. A Tippon establishes where that survey number sits on the ground and what shape it takes. That distinction surfaces in predictable situations:

• Boundary disputes when a neighbour claims part of your land, the Tippon is the baseline record to measure against.
• Partition and subdivision when family land is divided, the new sub-division sketch is drawn from the original Tippon.
• Bank loans lenders commonly require an FMB sketch to confirm dimensions before approving a mortgage.
• Sale registration sub-registrar offices in Telangana increasingly expect a Tippon or FMB to accompany the sale deed, particularly as the state moves toward sketch-mandatory registration.
• Government acquisition compensation for acquired land is calculated from the recorded extent in the Tippon and connected records.

The Tippon is the ground truth. The Pattadar Passbook is the ownership record. Most transactions need both.

Getting a Copy: Online View vs. Certified Copy

There are two distinct paths, and confusing them wastes time. The online route is for preliminary checks only. The offline route produces the stamped document that banks, courts, and sub-registrar offices accept.

Viewing a Sketch Online

Telangana’s land records portal transitioned from Dharani to Bhu Bharati in April 2025. The underlying data carried over, but the interface and some features changed.

1. Open the official Bhu Bharati portal.
2. Go to the land records or map section.
3. Select your district, mandal, and village.
4. Enter the survey number or Pattadar Passbook number.
5. View the cadastral map or available sketch.

Here’s the catch most people learn the hard way: the direct download of official plot-level Tippons has been restricted or disabled. The portal may display a village-level cadastral map, but a certified plot-level Tippon generally requires an offline application. Treat whatever you see online as a reference, not a substitute.

Applying for a Certified Copy

Step 1: Identify the right office. Certified copies come from the Survey and Land Records Department at district level, routed through the Mandal Revenue Office (MRO) or a Meeseva centre. The Mandal Surveyor does the actual processing after the Tahsildar approves the request.

Step 2: Prepare the application. Submit a written request containing the district, mandal, and village name; the survey number and sub-division number; your name and contact details; and a copy of your Pattadar Passbook, sale deed, or another document proving your connection to the land.

Step 3: Submit and get an acknowledgment. Take it to a Meeseva centre or the MRO directly. The service is usually listed as “Copy of FMB / Tippon” in the Meeseva menu. The staff will register the request and hand you an acknowledgment keep this safe, since it’s your only proof of submission if the file goes missing.

Step 4: Pay the prescribed fee. Charges vary by service type and get revised periodically. Certified copies carry nominal fees, while subdivision or demarcation-linked requests cost more. Check the official portal or your Meeseva centre for the current rate rather than trusting an old figure.

Step 5: Wait for processing. District citizen charters list 7 to 15 days for certified survey records. In practice, expect one to two weeks, depending on the Mandal Surveyor’s workload.

Step 6: Collect and verify. The document should carry the surveyor’s seal, signature, and a reference number. Before you leave the office, check that the survey number, extent, and boundary details match your records.

Common Mistakes That Delay Applications

Applying for the parent survey number instead of your sub-division. If your land is 45/2, requesting a sketch for survey number 45 alone won’t give you the right document. Confirm your exact sub-division from your Pattadar Passbook or latest Pahani before applying.

Treating a portal screenshot as sufficient. A Bhu Bharati view or an old Dharani map carries no legal weight. Sub-registrar offices and courts want the physical, stamped copy.

Ignoring how old the Tippon is. Older Tippons reflect the survey as it stood decades ago. If the land has since been subdivided or a boundary has shifted, the sketch won’t match the ground position. You may need a fresh survey or demarcation through the F-Line process.

Skipping the Section 22A check. Certain Telangana lands are flagged as prohibited under Section 22A of the Registration Act due to litigation or government acquisition. Even with a valid Tippon, registration can be blocked if the land appears on that list. Check prohibition status on the official portal before committing to a transaction.

Submitting an incomplete file. A missing passbook copy or an illegible survey number can push your application back by weeks. Verify the paperwork before you queue up.

You may also like to read these posts :👇

Old Pahani, Sethwar & Khasra Pahani (1954-55) Telangana: How to Get a Copy

Dharani EC Search: How to Get an Encumbrance Certificate in Telangana

ROR-1B & Adangal Telangana: Download 1B Online (Bhu Bharati Update)

Dharani / Bhu Bharathi App: Is There an Official App? Download & Alternatives

Frequently Asked Questions

If your transaction is time-sensitive, start the certified copy application before you finalise the sale agreement two weeks is a realistic buffer, and disputes over sub-division numbers can stretch it further.And if the Tippon you receive doesn’t match the ground, don’t proceed with registration on the assumption that it will sort itself out later. Resolve the discrepancy through an F-Line petition first; a mismatch discovered after registration is far more expensive to fix than one caught before it.
